HTB
Hydraulic thin-type Cylinder
‧Bore:Ø20-Ø80mm ‧Pmax:140kg/c㎡
Small solid , save space , the best choice.
Directly install , have no need other accessories , lower cost .
Standardized specification , good in appearance , long-lived to use .
Axial and side manifold without distributing tube ; integrated beautifully .
A camparision of length between
the traditional hydraulic cylinder
and thin type cylinder.
Installation type
Axial
Single end rod SD ; Double end rod SW
Side
Single end rod LA ; Double end rod LW
The range of pressure
5-140kg/c㎡
The range of speed
8-100mm/sec
The range of temperature
-10~60℃
Fluid
Filtered oil
Acting type
Double acting
Material of cylinder barrel
Carbon steel
UNIT:kg
SD
SDM
LA
LAM
